Flexible Gravity Roller Conveyor,Expandable No Power Roller Conveyor

Description

Flexible Expandable Gravity Roller Conveyor is designed especially to convey flat base loads,such as different sized boxes,cases and cartons,etc.It can be expanded if you require a longer system or bent into curves or even compacted for better storage when not in use.Whats more,this conveyor is very easy to quick manoeuvre in or out of trucks for faster,safer,easier loading and unloading materials.

Specification

Model	Extendable Length	Effective Width	Adjustable Height	Max.Load	Roller Dia	Roller Material
FGR-2	1120-2500mm (3.6'-8.2')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-3	1580-3600mm (5.1'-11.8')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-4	2040-4700mm (6.6'-15.4')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-5	2500-5800mm (8.2'-19')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-6	2960-6900mm (9.7'-22.6')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-7	3420-8000mm (11.2'-26.2')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-8	3880-9100mm (12.7'-29.8')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-9	4340-10200mm (14.2'-33.4')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel
FGR-10	4800-11300mm (15.7'-37')	600 mm	700-1000mm (27-1/2" to 39-1/2")	50kg/m	50mm	Plastic,Steel

Features

Φ50mm galvanized steel rollers with precise bearings guarantee fairly low noise and long life span.
Twin PVC rollers,stainless steel rollers also available for certain sensitive cargo.
Effective roller width are 600mm as standard(300mm~1000mm as options).
50kg per linear meter load capacity
Heavy duty powder coated steel side plates ensure maximum strength and durability,bright Zinc plated side plates also available.
Supporting legs are fully adjustable from 700mm to 1000mm as standard(800mm to 1200mm as option).
Easy to move around on Dia 100mm heavy duty lockable swivel polyurethane casters.
With package stop end bar to prevent cartons from falling off the conveyors.
Can be made in custom lengths to suit your individual conveying application.
Quickly and easily join two or more units together to expand your system.

Packing and Shipping

①　Take off legs and packed in cartons.

②　Lay conveyor bodies on plywood pallets and wrapped with cardboard, bubble film and stretch film.Then put the leg cartons over the pallet and fix them together by bandage.

Contact Us

Ningbo YiFan Conveyor Equipment Co.,Ltd.

Email: sales@yfconveyor.com

Web: http://www.yfconveyor.com

Tel:+86 574 8630 1900

Fax:+86 574 8630 1900

Mob:+86 139 5824 8487

FAQ

What is the Max.Length can you make?
20m
Can we join two units to expand the system?
YES, quickly and easily join together by hooks
Can the width be customized?
YES
What is the Min.width do you have?
350mm
What is the Max.width do you have?
YES
Is the height adjustable?
YES, 700-1000mm or 800-1200mm
Can the height be customized?
YES
Do you have stainless steel 304 rollers?
YES
Do you have PVC rollers?
YES
How many KGS can this conveyor carry?
50KGS per square meter
What products can this conveyor be used to load?
Cartons,boxes with FLAT & HARD bottoms
How do you dispatch this conveyor?
Dispatch it completely
How many countries have you sell this conveyor to?
UK,America,France,Canada,Russia,Romania,Chile,Jordan,UAE,Spain,Qatar,Kenya,South Africa,Iran,Pakistan,Vietnam,Philippines,etc.
How long is the delivery time?
10-15 days
How long is the warranty?
1 year
Do you supply OEM & ODM service?
YES
Do you have user’s guide and maintenance instruction?
YES
What are the necessary spare parts we should keep?
wheels,screws
