Description
This is a type of expandable,flexibe and durable conveyors for loose loading and unloading applications.
Features
Portable & movable
Loading & unloading
Inside truck part with 2m expandable powered roller conveyor
Good load capacity of 50kgs per meter
Can be combined with other flexible conveyors to expand your systems.
Specifications
| Belt Width | 600mm |
| Belt Type | 5mm thickness good grip black PVC belt |
| Belt Speed | 10-22m/min,forward & reverse |
| Belt Motor | 1.5kw |
| Lift Motor | 2.2kw (manual lift available) |
| Lift Structure | screw |
| Extendable Length | 5000mm-6000mm |
| Adjustable Height | 800mm-1900mm |
| Control Box | OFF/ON,Forward/Reverse,Up/Down,Emergency Stop,Function Switch,Speed Knob,LED Display |
| Inside Truck Part | 2m powered extendable rollers or 4m gravity extendable wheels |
Movable on universal lockable casters
| Model | Belt Width | Motor Power | Load Capacity | Adjustable Height | Variable Speed | Machine Weight |
| ML-S400 | 400mm | 1.5 & 2.2kw | 30kg/m | 700-2500mm | 10-22m/min | 450kgs |
| ML-S600 | 600mm | 1.5 & 2.2kw | 50kg/m | 700-2500mm | 10-22m/min | 590kgs |
| ML-S800 | 800mm | 1.5 & 2.2kw | 70kg/m | 700-2500mm | 10-22m/min | 750kgs |
Drawing
